AXISP5635-EPTZMkIIDomeNetworkCamera
TechnicalSpecifications
10–pinPush-PullSystemConnector
FunctionPinNotes
Specications
AC/DCPower
input
9,10
Theinputispolarityindependent.UseaSafetyExtraLow
Voltage(SELV)compliantlimitedpowersource(LPS)with
eitheraratedoutputpowerlimitedto≤100Worarated
outputcurrentlimitedto≤5A.
24VAC/DC
Digitalinput–Connecttopin8toactivate,orleave
oating(unconnected)todeactivate.
0tomax30VDC Congurable
(InputorOutput)
3–I/O1
5–I/O2
6–I/O3
7–I/O4
Digitaloutput–Connectedtopin8whenactivated,
oating(unconnected)whendeactivated.Ifusedwithan
inductiveload,e.g.arelay,adiodemustbeconnected
inparallelwiththeload,forprotectionagainstvoltage
transients.
0tomax30VDC,opendrain,
100mA
DCOutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
12VDC
Maxload=50mA
GND
8
GroundforaudioandI/O
AudioLineOut
4
Canbeconnectedtoapublicaddress(PA)systemoran
activespeakerwithabuilt-inamplier
AudioIn
1
Balancedorunbalancedinputforamonomicrophone
orlinesignal
PerformanceConsiderations
Whensettingupyoursystem,itisimportanttoconsiderhowvarioussettingsandsituationswillaffectperformance.Somefactors
affecttheamountofbandwidth(thebitrate)required,otherscanaffecttheframerate,andsomeaffectboth.Iftheloadonthe
CPUreachesitsmaximum,thiswillalsoaffecttheframerate.
Thefollowingfactorsareamongthemostimportanttoconsider:
•Highimageresolutionand/orlowercompressionlevelsresultinimagescontainingmoredata.Bandwidthaffected.
•AccessbylargenumbersofMotionJPEGand/orunicastH.264clients.Bandwidthaffected.
•Simultaneousviewingofdifferentstreams(resolution,compression)bydifferentclients.Effectonframerateand
bandwidth.
•AccessingMotionJPEGandH.264videostreamssimultaneously.Framerateandbandwidthaffected.
•Heavyusageofeventsettingsaffecttheproduct’sCPUload.Framerateaffected.
•UsingHTTPSmayreduceframerate,inparticularifstreamingMotionJPEG.
•Heavynetworkutilizationduetopoorinfrastructure.Bandwidthaffected.
•Viewingonpoorlyperformingclientcomputerslowersperceivedperformance.Framerateaffected.
69
