Axis P8221 Installation Guide

AXIS P8221 Installation Guide Page 7
ENGLISH
AXIS IP Utility - single device/small installation
AXIS IP Utility automatically discovers and displays Axis devices on your network. The application
can also be used to manually assign a static IP address.
Note that the computer running AXIS IP Utility must be on the same network segment (physical
subnet) as AXIS P8221.
Automatic discovery
1. Check that AXIS P8221 is connected to the network and that power has been applied.
2. Start AXIS IP Utility.
3. When AXIS P8221 appears in the window, double-click to open its home page.
4. See page 9 for instructions on how to assign the password.
Set the IP address manually (optional)
1. Acquire an unused IP address on the same network segment as your computer.
2. Select AXIS P8221 in the list.
3. Click the button Assign new IP address to selected device and enter the IP address.
4. Click the Assign button and proceed according to instructions.
5. Click the Home Page button to access the device’s web pages.
6. See page 9 for instructions on how to set the password.

Axis P8221 Specifications

General

Relay Outputs	2
Digital Inputs	4
Enclosure	Plastic
Audio Output	Terminal block for one balanced audio output
Power over Ethernet	Yes
Connectors	Terminal block
Power	PoE (IEEE 802.3af)
Protocols	HTTP, HTTPS, SSL/TLS, IPv4, IPv6, Bonjour, UPnP, QoS, SNMP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, DNS
Network Interface	10/100 Mbit/s Ethernet
Output channels	2
Input type	Digital, audio
Maximum load voltage per output	30 V DC
Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Dimensions (alternative)	4.3 x 2.9 x 1.4 in
Weight (alternative)	0.3 lb
