Axis P8221 Installation Guide

Page 8 AXIS P8221 Installation Guide
AXIS Camera Management - multiple devices/large installations
AXIS Camera Management can automatically discover multiple Axis devices, show connection
status, manage firmware upgrades and set IP addresses.
Automatic discovery
1. Check that AXIS P8221 is connected to the network and that power has been applied.
2. Start AXIS Camera Management. When AXIS P8221 appears in the window, right-click the link
and select Live View Home Page.
3. See page 9 for instructions on how to set the password.
Assign an IP address in a single device
1. Select AXIS P8221 in AXIS Camera Management and click the Assign
IP button .
2. Select Assign the following IP address and enter the IP address, the
subnet mask and default router for the device.
3. Click OK.
Assign IP addresses in multiple devices
AXIS Camera Management speeds up the process of
assigning IP addresses to multiple devices, by suggesting
IP addresses from a specified range.
1. Select the devices you wish to configure (different
models can be selected) and click the Assign IP
button.
2. Select Assign the following IP address range and
enter the range of IP addresses, the subnet mask and
default router the devices will use.
3. Click Update. Suggested IP addresses are listed under
New IP Addresses and can be edited by selecting a
device and clicking the Edit button.
4. Click OK.

Axis P8221 Specifications

General

Relay Outputs	2
Digital Inputs	4
Enclosure	Plastic
Audio Output	Terminal block for one balanced audio output
Power over Ethernet	Yes
Connectors	Terminal block
Power	PoE (IEEE 802.3af)
Protocols	HTTP, HTTPS, SSL/TLS, IPv4, IPv6, Bonjour, UPnP, QoS, SNMP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, DNS
Network Interface	10/100 Mbit/s Ethernet
Output channels	2
Input type	Digital, audio
Maximum load voltage per output	30 V DC
Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Dimensions (alternative)	4.3 x 2.9 x 1.4 in
Weight (alternative)	0.3 lb
