Axis Q1615-E Mk II Installation Guide

AXISQ1615-EMkIINetworkCamera
InstallationGuide
ThisInstallationGuideprovidesinstructionsforinstallingAXISQ1615-EMkIINetworkCamera
onyournetwork.Forotheraspectsofusingtheproduct,seetheUserManualavailableat
www.axis.com
InstallationSteps
1.Makesurethepackagecontents,toolsandothermaterialsnecessaryfortheinstallation
areinorder.Seepage9.
2.Studytheproductoverview.SeeProductoverviewonpage10
3.Studythespecications.Seepage17.
4.Installthehardware.Seepage19.
Packagecontents
•AXISQ1615–EMkIINetworkCamera
•4–pinI/Oconnectorblockforconnectingexternaldevices
•2–pinRS485/422connectorblock(x2)
•Wallmount
•TorxscrewdriverT20
•Printedmaterials
-InstallationGuide(thisdocument)
-Extraserialnumberlabel(2x)
-AVHSAuthenticationkey
OptionalAccessories
Forinformationaboutavailableaccessories,includingpoweraccessoriesandoutdoorhousings
seewww.axis.com
9
EN
