Axis Q1635 Installation Guide

AXISQ1635NetworkCamera
5.
I/Oconnector
6.
Irisconnector
7.
Powerconnector
8.
PowerLEDindicator
9.
NetworkLEDindicator
10.
RS485/RS422connector
11.
Networkconnector(PoE)
12.
Controlbutton(1)
13.
Functionbutton(2)
14.
microSDCardslot
15.
Audioin
16.
Audioout
Important
IftheAxisproductisinstalledinanexternalcamerahousing,leaveanunobstructedcylinder-shaped
zonewithØ85mm(33/8in)aroundthelenstoenablelensmovementswithinthehousing.
>Ø85
mm (3 3/8 in)
>Ø85
mm (3 3/8 in)
>Ø85 mm (3
3/8 i
n
)
11
