Axis Q1635 Installation Guide

AXISQ1635NetworkCamera
InstalltheHardware
NO NO
NO
TICE TICE
TICE
Duetolocalregulationsortheenvironmentalandelectricalconditionsinwhichthe
productistobeused,ashieldednetworkcable(STP)maybeappropriateorrequired.Any
networkcablesthatareroutedoutdoorsorindemandingelectricalenvironmentsshallbe
shielded(STP)andintendedfortheirspecicuse.
1.Optionallyconnectexternalinput/outputdevices,suchasalarmdevices.Seeonpage15
forinformationontheterminalconnectorpins.
2.Optionallyconnectanactivespeakerand/orexternalmicrophone.
3.Connectthecameratothenetworkusingashieldednetworkcable.
4.Connectpower,usingoneofthemethodslistedbelow:
-PoE(PoweroverEthernet).PoEisautomaticallydetectedwhenthenetwork
cableisconnected.
-Connectanexternalpoweradaptertothepowerconnectorblock.See
ConnectorsandButtonsonpage13.
5.CheckthattheindicatorLEDsindicatethecorrectconditions.Seethetableonpage
12formoredetails.NotethattheStatusLEDcanbeconguredtobeunlitduring
normaloperation.
6.OptionallyinsertamicroSDcard(notincluded)intotheSDcardslot.
NO NO
NO
TICE TICE
TICE
Topreventcorruptionofrecordings,theSDcardshouldbeunmountedbeforeitisejected.
Tounmount,gotoSetup>SystemOptions>Storage>SDCardandclickUnmount.
AccesstheProduct
UsethetoolsprovidedontheInstallationandManagementSoftwareCDtoassignanIPaddress,
setthepasswordandaccessthevideostream.Thisinformationisalsoavailablefromthesupport
pagesonwww.axis.com/techsup/
AdjustFocus
Toadjustthezoomandfocusfollowtheseinstructions:
Note
•SetfocusaspreciselyaspossiblewiththefocusringorFocusAssistantbeforestarting
automaticnetuning.Usingthefocusringnormallygivesthebestresult.
•Theirisshouldalwaysbeopenedtoitsmaximumwhilefocusing.Thisgivesthesmallest
depthofeldandthusthebestconditionsforcorrectfocusing.
19
