AXIS
Q1635
Network
Camera
Audio
Connector
3.5
mm
audio
connectors
(stereo)
1
2
3
1
Tip
2
Ring
3
Sleeve
Audio
Input
Microphone/Line
in
Ground
Audio
Output
Line
out
(mono)
Ground
RS485/422
Connector
Two
2-pin
terminal
blocks
for
RS485/RS422
serial
interface.
The
serial
port
can
be
congured
to
support:
•
Two-wire
RS485
half
duplex
•
Four-wire
RS485
full
duplex
•
Two-wire
RS422
simplex
•
Four-wire
RS422
full
duplex
point
to
point
communication
R
S
4
8
5
/
4
2
2
1
2
R
X
/
T
X
T
X
3
4
Function
Pin
Notes
RS485B
alt
RS485/422
RX(B)
1
RS485A
alt
RS485/422
RX(A)
2
RX
pair
for
all
modes
(combined
RX/TX
for
2-wire
RS485)
RS485/RS422
TX(B)
3
RS485/RS422
TX(A)
4
TX
pair
for
RS422
and
4-wire
RS485
Important
The
recommended
maximum
cable
length
is
30
m
(98.4
ft).
SD
Card
Slot
Supports
microSD
cards
with
up
to
64
GB
of
storage.
For
best
recording
performance,
use
a
microSDHC
UHS-I
or
microSDXC
UHS-I
card.
In
temperatures
below
–
25°
C
use
industrial
grade
SD
card.
18
17
19
