AXISQ1635NetworkCamera
StatusLEDBehaviorforFocusAssistant
Color
Indication
Green
FocusAssistantisenabled
Thelensisoptimallyadjusted
AmberThecamerahasbeenmoved,oranobjecthasbeeninsertedinfrontofthelens.
ExitandrestarttheFocusAssistant.
Thelensislessoptimallyadjusted.
RedThecamerahasbeenmoved,oranobjecthasbeeninsertedinfrontofthelens.
ExitandrestarttheFocusAssistant.
Thelensispoorlyadjusted.
BuzzerSignalforFocusAssistant
BuzzerLens
Fastinterval
Optimallyadjusted
MediumintervalLessoptimallyadjusted
Slowinterval
Poorlyadjusted
StatusLEDBehaviorandBuzzerSignalforLevellingAssistant
ForinformationontheFunctionbuttonusedforlevellingthecamera,seeConnectorsandButtons.
Pressandholdthefunctionbutton(2)formorethantwosecondstolevelthecamera.
•Whenthecameraislevel,bothLEDsaresteadygreen,andthebeepiscontinuous.
•Whenthecameraisnotlevel,theLEDsashacombinationofred,greenandorange,and
thebeepoccursatslowintervals.
BothLEDsbrieyashgreentoindicatethatthelevellingisgettingbetter.
ConnectorsandButtons
Forspecicationsandoperatingconditions,seepage15.
NetworkConnector
RJ45EthernetconnectorwithPoweroverEthernet(PoE).
