AXISQ1635NetworkCamera

I/Oconnector

4–pinterminalblockfor:

•0VDC(-)

•Auxiliarypower(DCoutput)

•DigitalInput

•DigitalOutput

2 3 4

FunctionPinNotes

Specications

0VDC(-)

DCoutput

Canbeusedtopowerauxiliaryequipment.

Note:Thispincanonlybeusedaspowerout.

12VDC

Maxload=50mA

Digitalinput–Connecttopin1toactivate,

orleaveoating(unconnected)todeactivate.

0tomax30VDC Congurable

(Inputor

Output)

3–

Digitaloutput–Connectedtopin1when

activated,oating(unconnected)when

deactivated.Ifusedwithaninductiveload,

e.g.arelay,adiodemustbeconnectedin

parallelwiththeload,forprotectionagainst

voltagetransients.

0tomax30VDC,open

drain,100mA

Axis Q1635 Installation Guide
