Axis Q1765-LE - Connection Diagrams; Performance Considerations

AXISQ1765-LENetworkCamera
TechnicalSpecifications
Weight
1.8kg(4.0lb)includingthebracket
Included
accessories
Connectorkit,InstallationGuide,RecordingsoftwareandUser’sManual,Windowsdecoder1-userlicense,Allenkey
AXISQ1765FootChassis
AXISQ1765-LEFrontKit
AXIST94G01SMountingPlate
AXISSunshieldB
Optional
accessories
AXIST8604MediaConverterSwitch
AXIST91A47PoleMount
AXIST94P01BCornerBracket
Video
management
software
AXISCameraCompanion,AXISCameraStation,VideomanagementsoftwarefromAxis’ApplicationDevelopment
Partnersavailableonwww.axis.com/techsup/software
Languages
English,German,French,Spanish,Italian,Russian,SimpliedChinese,Japanese,Korean,Portuguese
Warranty
Axis3-yearwarrantyandAXISExtendedWarrantyoption,seewww.axis.com/warranty
a.ThisproductincludessoftwaredevelopedbytheOpenSSLProjectforuseintheOpenSSLToolkit.(www.openssl.org),and
cryptographicsoftwarewrittenbyEricYoung(eay@cryptsoft.com).
Moreinformationisavailableatwww.axis.com
ConnectionDiagrams
I/OConnector
1
0VDC(-)
2
DCoutput12V,max50mA
A
I/Oconguredasinput
B
I/Oconguredasoutput
PerformanceConsiderations
Whensettingupyoursystem,itisimportanttoconsiderhowvarioussettingsandsituationswillaffectperformance.Somefactors
affecttheamountofbandwidth(thebitrate)required,otherscanaffecttheframerate,andsomeaffectboth.Iftheloadonthe
CPUreachesitsmaximum,thiswillalsoaffecttheframerate.
