AXISQ1765-LENetworkCamera
HardwareOverview
•Input/Output(I/O)devices
Whenconnectingexternalequipment,amulti-connectorcable(availablefromAxis)isrequiredinordertomaintaintheproduct’sIP
rating.Formoreinformation,seeMulti-ConnectorCable(soldseparately)onpage59.
PowerConnector
TerminalconnectorforconnectingAC/DCpowersupply.
SDCardSlot
NO NO
NO
TICE TICE
TICE
•RiskofdamagetoSDcard.DonotusesharptoolsorexcessiveforcewheninsertingorremovingtheSDcard.
•Riskofdataloss.Topreventdatacorruption,theSDcardshouldbeunmountedbeforeremoval.Tounmount,gotoSetup>
SystemOptions>Storage>SDCardandclickUnmount.
ThisproductsupportsmicroSD/microSDHC/microSDXCcards(notincluded).
ForSDcardrecommendations,seewww.axis.com
ControlButton
Forlocationofthecontrolbutton,seeHardwareOverviewonpage7.
Thecontrolbuttonisusedfor:
•Resettingtheproducttofactorydefaultsettings.Seepage57.
•ConnectingtoanAXISVideoHostingSystemservice.Seepage49.Toconnect,pressandholdthebuttonforabout3
secondsuntiltheStatusLEDashesgreen.
•ConnectingtoAXISInternetDynamicDNSService.Seepage49.Toconnect,pressandholdthebuttonforabout3seconds.
LEDIndicators
Note
•TheStatusLEDcanbeconguredtobeunlitduringnormaloperation.Tocongure,gotoSetup>SystemOptions>Ports
&Devices>LED.Seetheonlinehelpformoreinformation.
•TheStatusLEDcanbeconguredtoashwhileaneventisactive.
•TheStatusLEDcanbeconguredtoashforidentifyingtheunit.GotoSetup>SystemOptions>Maintenance.
StatusLED
Indication
Unlit
Connectionandnormaloperation.
GreenShowssteadygreenfor10secondsfornormaloperationafterstartupcompleted.
Amber
Steadyduringstartup.Flashesduringrmwareupgrade.
Amber/RedFlashesamber/redifnetworkconnectionisunavailableorlost.
RedFlashesredforrmwareupgradefailure.
8

Axis Q1765-LE Specifications

Camera

image sensor	1/2.9" progressive scan RGB CMOS
lens	f=4.7–84.6 mm, F1.6–2.8, Autofocus, Automatic day/night
horizontal angle of view	59° to 4°

Video

shutter time	1/28000 s to 2 s
video resolutions	1920x1080 (HDTV 1080p) to 320x180
frame rate	Up to 30/25 fps (60/50 Hz) in all resolutions

Operating Environment

operating temperature	-40 °C to 50 °C (-40 °F to 122 °F)
humidity	10–100% RH (condensing)
casing	IP66- and NEMA 4X-rated, impact-resistant aluminum enclosure

Power

power over ethernet	IEEE 802.3af; max 12.95 W
power input	8-28 V DC max 15.2 W
power input AC	20-24 V AC max 22.0 VA

Memory and Storage

memory	256 MB RAM, 128 MB Flash
edge storage	MicroSD/microSDHC/microSDXC slot up to 64 GB
recording support	network share (NAS or file server)

Weight and Dimensions

weight with bracket	1.8 kg (4.0 lb)
optical zoom	18x
digital zoom	12x
