AXIS Q19 Series Installation Guide Page 13
ENGLISH
Connect the cables
1. Optionally insert an SD card (not included) into the SDHC (Secure Digital High
Capacity) card slot. A standard or high capacity SD card is required to store images locally in
the camera.
2. Optionally connect external input/output devices. See page 22 for information on the terminal
connector pins.
3. Optionally connect an active speaker and/or external microphone.
4. Connect the camera to the network.
5. Connect power, using one of the methods listed below:
• PoE (Power over Ethernet, Class 3). If available, this is automatically detected when the
network cable is connected.
• Connect an external power adapter to the power connector block, see Resetting to the Fac-
tory Default Settings, on page 22 for wiring information.
6. Check that the indicator LEDs indicate the correct conditions. See the table on page 10 for
further details.
