Page 8 AXIS Q1931-E PT Mount Installation Guide
1/4 in UNC
70 mm
(2.76 in)
RS485/422
A+
RXTX
B- A+ B-
RS485
RX/TX
A+ B-
Power over Ethernet
IEEE 802.3af/
802.3at Type 1 Class 3
8-28 V DC max 13.7 W
20-24 V AC max 20.2 VA
+/-
~
-/+
~
