AXISQ3505–VFixedDomeNetworkCamera
NO NO
NO
TICE TICE
TICE
Topreventcorruptionofrecordings,theSDcardshouldbeunmountedbeforeremoval.To
unmount,gotoSetup>SystemOptions>Storage>SDCardandclickUnmount.
Note
ForSDcardrecommendationsseewww.axis.com
ControlButton
Thecontrolbuttonisusedfor:
•Resettingtheproducttofactorydefaultsettings.Seepage21.
•ConnectingtoanAXISVideoHostingSystemserviceorAXISInternetDynamicDNS
Service.Formoreinformationabouttheseservices,seetheUserManual.
FunctionButton
Thefunctionbuttonhasmultiplefunctions:
•AsLevellingAssistant–Thisfunctionhelpstoensuretheimageislevel.Pressthe
buttonforabout2secondstostartthelevellingassistantandpressagaintostop.The
statusLED(seepage12)andbuzzersignalassistlevellingoftheimage.Theimageis
levelwhenthebuzzerbeepscontinuously.
•ToviewtheStatusLED–PressthebuttononcetolightuptheStatusLEDs.Pressagain
toturnthemoff.TheLEDswillturnoffautomaticallyafter10seconds.
Multicable(soldseparately)
ThemulticablecanbepurchasedfromanAxisresellerforconnectingexternalequipmenttothe
Axisproduct.Thecableprovidesthefollowingconnectors:
Audioconnector-SeeConnectorsonpage15
I/Oconnector-SeeConnectorsonpage15
Powerconnector-ConnectorforACandDCpowerforconnectiontotheAXIST8051Power
ConverterAC/DCtoDC(notincluded)wires.
Wires
Specications
Red
+DCorAC
Black
–DCorAC
