AXISQ3505–VFixedDomeNetworkCamera
ConnectorsandButtons
Forspecicationsandoperatingconditions,seepage15.
NetworkConnector
RJ45EthernetconnectorwithPoweroverEthernet(PoE).
NO NO
NO
TICE TICE
TICE
Theproductshallbeconnectedusingashieldednetworkcable(STP).Allcablesconnecting
theproducttothenetworkshallbeintendedfortheirspecicuse.Makesurethatthe
networkdevicesareinstalledinaccordancewiththemanufacturer’sinstructions.For
informationaboutregulatoryrequirements,seeElectromagneticCompatibility(EMC)on
page2.
I/OConnector
Usewithexternaldevicesincombinationwith,forexample,tamperingalarms,motiondetection,
eventtriggering,timelapserecordingandalarmnotications.Inadditiontothe0VDCreference
pointandpower(DCoutput),theI/Oconnectorprovidestheinterfaceto:
DigitaloutputForconnectingexternaldevicessuchasrelaysandLEDs.Connected
devicescanbeactivatedbytheVAPIX®ApplicationProgrammingInterface,output
buttonsontheLiveViewpageorbyanActionRule.Theoutputwillshowasactive
(shownunderSystemOptions>Ports&Devices)ifthealarmdeviceisactivated.
DigitalinputAnalarminputforconnectingdevicesthatcantogglebetweenanopen
andclosedcircuit,forexample:PIRs,door/windowcontacts,glassbreakdetectors,
etc.Whenasignalisreceivedthestatechangesandtheinputbecomesactive(shown
underSystemOptions>Ports&Devices).
AudioConnector
TheAxisproducthasthefollowingaudioconnectors:
Audioin(pink)3.5mminputforamonomicrophone,oraline-inmonosignal.
Audioout(green)3.5mmoutputforaudio(linelevel)thatcanbeconnectedto
apublicaddress(PA)systemoranactivespeakerwithabuilt-inamplier.Astereo
connectormustbeusedforaudioout.
SDCardSlot
AmicroSDcard(notincluded)canbeusedforlocalrecordingwithremovablestorage.Formore
information,seeSpecicationsonpage15.
13
ENGLISH

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Axis Q3505-V and is the answer not in the manual?

Axis Q3505-V Specifications

General IconGeneral
ModelAxis Q3505-V
Camera TypeFixed Dome
EnvironmentIndoor/Outdoor
ConnectivityEthernet
Image SensorProgressive scan RGB CMOS
Resolution1920x1080
Day/Night FunctionalityYes
IR IlluminatorsNo
Wide Dynamic RangeYes
Audio SupportTwo-way audio
Local StorageMicroSD card slot
Ethernet10Base-T/100Base-TX
Ingress ProtectionIP66
Frame RateUp to 60 fps
Lens TypeVarifocal
CompressionH.264, MJPEG
Power over EthernetYes
Operating Temperature50 °C
Sensor Size1/2.8"
