AXIS Q60-S Series
Congurable
I/O 1 (Input or Output)
3
Digital input
0 to max 30 V DC
Digital output (transistor
open collector)
0 to max 30 V DC,
open drain, 100 mA
Congurable
I/O 2 (Input or Output)
5
Digital input
0 to max 30 V DC
Digital output (transistor
open collector)
0 to max 30 V DC,
open drain, 100 mA
ENGLISH
Camera Connectors
Power connector
Two 2-pin terminal blocks for power output (pin 4
is not used).
+ +
21 43
-
Function Pin Notes
Specications
DC
output
12 V DC
1, 2
Power out to camera
12.0-13.2 V DC,
min 70 W
0 V DC (-)
3
0 V DC
N/a
4
N/a
Network connector
Two 2-pin Ethernet terminal blocks.
I/O terminal connector
2-pin terminal block.
21
