AXISQ6044PTZDomeNetworkCamera

VideoandAudio

4.Toincludeatextstring,selectIncludetextandenterthetextintheeld.Modierscanbeused,seeFileNaming&

Date/TimeFormatsintheonlinehelp.

5.Denetextoverlaycharacteristicsintherelevantelds.

6.ClickSave.

Tomodifythedateandtimeformat,gotoSystemOptions>Date&Time.SeeDate&Timeonpage49.

DisplayingthePanPositionasaTextOverlay

Itmaybeusefultoretrieve,forinstancefromarecordedvideo,thepanposition(indegrees)inwhichaneventhastakenplace.

Thiscanbeobtainedbyincludingthepanpositionintheimageasatextoverlay,usingamodier.Todisplaythepanpositionasa

textoverlay:

1.GotoSetup>Video>VideoStream.

2.UnderOverlaysettings,selectIncludetextandenter#x.

3.Conguretheoptionalsize,colorandpositonofthetextoverlay.

4.ClickSave.

OverlayImage

Anoverlayimageisastaticimagesuperimposedoverthevideostream.Theimage,forexampleacompanylogo,isusedtoprovide

extrainformationortomaskapartoftheimage.

Sinceitisstatic,thepositionandsizeofanoverlayimagewillremainthesameregardlessofresolutionandPan/Tilt/Zoommovements.

Useaprivacymasktosetupadynamicmaskwhichwillalwaysmaskthespeciedpartofmonitoredarea.

Formoreinformationaboutprivacymasks,seePrivacyMaskonpage24.

Touseanoverlayimage,theimagemustrstbeuploadedtotheAxisproduct.TheuploadedimageshouldbeaWindows24-bitBMP

imagewithmaximum250colors.Theimagewidthandheight,inpixels,mustbeexactlydivisibleby4andcannotbelargerthanthe

maximumimageresolution.Ifcombiningtextandimageoverlays,takeintoconsiderationthatthetextoverlayoccupies16or32

pixelsinheight(dependingontheresolution)andhasthesamewidthasthevideoimage.

ToautomaticallyscaletheimagetotheresolutionusedbytheAxisproduct,selecttheoptionScalewithresolutionfromthe

TransparencySettingspagewhichisdisplayedwhenuploadingintheimage.

Touploadanoverlayimage:

1.GotoVideo&Audio>OverlayImage.

2.ClickBrowseandbrowsetothele.

3.ClickUpload.

4.TheTransparencySettingspageisnowdisplayed:

-Tomakeacolorintheoverlayimagetransparent,selectUsetransparencyandentertheRGBhexadecimalvalue

forthecolor.Example:Tomakewhitetransparent,enterFFFFFF.

Formoreexamplesofhexadecimalvalues,seetheonlinehelp

-Toscaletheimageautomatically,selectScalewithresolution.Theimagewillbescaleddowntotthe

resolutionusedbytheAxisproduct.

5.ClickSave.

Toselecttheimagetouseasoverlay:
