Axis Q6044 User Manual

AXISQ6044PTZDomeNetworkCamera
HardwareOverview
HardwareOverview
NO NO
NO
TICE TICE
TICE
Makesurethedomeisattachedinoperationmode,otherwisefocusmaybeaffected.
3
4
2
1
7
8
5
6
1
Partnumber(P/N)&Serialnumber(S/N)
2
Networkconnector(PoE+)
3
Multi-connector
4
Dome
5
SDcardslot
6
StatusLEDindicator
7
Controlbutton
8
Powerbutton
ConnectorsandButtons
Fortechnicalspecications,seepage65.
NetworkConnector
RJ45EthernetconnectorwithPoweroverEthernetPlus(PoE+).
NO NO
NO
TICE TICE
TICE
Usethesuppliedmidspan.
NO NO
NO
TICE TICE
TICE
Duetolocalregulationsortheenvironmentalandelectricalconditionsinwhichtheproductistobeused,ashieldednetwork
cable(STP)maybeappropriateorrequired.Allcablesconnectingtheproducttothenetworkandthatareroutedoutdoors
orindemandingelectricalenvironmentsshallbeintendedfortheirspecicuse.Makesurethatthenetworkdevices
areinstalledinaccordancewiththemanufacturer’sinstructions.Forinformationaboutregulatoryrequirements,see
ElectromagneticCompatibility(EMC)onpage2.
