AXISQ6045-SMkIIPTZDomeNetworkCamera
Hardwareoverview
Hardwareoverview
Forspecicationsofthehardwarecomponents,seeTechnicalspecicationsonpage64.
NO NO
NO
TICE TICE
TICE
Makesurethedomeisattachedinoperationmode,otherwisefocusmaybeaffected.
1
Pressurereliefvalve
2
Multiconnector
3
Hookforsafetywire
4
Inletvalve
5
Mountinghole(3x)
6
Partnumber(P/N)&Serialnumber(S/N)
7
Dome
8
SDcardslot(SDHC)
9
StatusLEDindicator
10
Controlbutton
