AXISQ7401VideoEncoder
Howtoinstalltheproduct
Installthehardware
Mountthevideoencoder
Thevideoencoderissuppliedwithamountingkitcontainingscrews,plugs,andprotectivepadsfor
mountingthevideoencodertoaconcretewall:
1.Placethevideoencoderagainstthewall,andmarkthelocationofthetwomounting
holes(seepage8)throughwhichthevideoencoderwillbeattached.
2.Removethevideoencoderanddrillthetwomountingholes.
3.Punchoutthefourprotectivepadsandapplythemtotheundersideofthevideoencoder.
4.Insertthewallplugsintothewall,positionthevideoencoder,andattachittothewall
usingthescrewsprovided.
Connectthecables
1.Connecttheencodertothenetworkusingashieldednetworkcable.
2.Optionallyconnectexternalinput/outputdevices,e.g.alarmdevices.Seepage13for
informationontheterminalconnectorpins.
3.Optionallyconnectanactivespeakerand/orexternalmicrophone.
4.Connectthecamera.
5.Connectpower,usingoneofthemethodslistedbelow:
-PoE(PoweroverEthernet).Ifavailable,thisisautomaticallydetectedwhen
thenetworkcableisconnected(seeabove).
-Connectthesuppliedindoorpowersupplytothepowerconnectoronthe
encoder.
6.CheckthattheindicatorLED:sindicatethecorrectconditions.Seepage13forfurther
details.
Howtoaccesstheproduct
AXISIPUtilityandAXISCameraManagementarerecommendedmethodsforndingAxisproducts
onthenetworkandassigningthemIPaddressesinWindows®.Bothapplicationsarefreeandcan
bedownloadedfromaxis.com/support
Theproductcanbeusedwithmostoperatingsystemsandbrowsers.Werecommendthefollowing
browsers:
•InternetExplorer
®
withWindows
®
•Safari
®
withOSX
®
•Chrome
TM
orFirefox
®
withotheroperatingsystems.
Formoreinformationaboutusingtheproduct,seetheUserManualavailableataxis.com
10
