Seite 36
AXIS Q7424-R Installationsanlei
tung
Hardwareübersicht
Abmessungen
1.
LED-Betriebsanzeige
2.
LED-Statusanzeige
3.
LED-Netzwerkanzeige
4.
Halterungslöcher
5.
Videoeingangsbuchsen
6.
SD-Speicherkarteneinschub
7.
E/A-Anschluss
8.
Audio-Anschlüsse
9.
SFP-Anschluss
10.
RS-485/RS-422-Anschluss
11.
Steuertaste
12.
Netzanschluss
13.
Netzwerkanschluss (mit PoE)
14.
SD-Speicherkartenabdeckung
AXIS Q7424-R
H x B x T = 45 x 135 x 167 mm
Gewicht = 0,8 kg
Vorderansicht
Rückansicht
5
6
7
8
9
2
1
3
4
10
11
12
13
14
35
37
