AXISQ8685-EPTZNetworkCamera
AboutPTZ(PanTiltZoom)
Note
DisablingPTZcontrolswillnotaffectpresetpositions.Forexample,ifthetiltcontrolisdisabled,theproductcanstillmoveto
presetpositionsthatrequireatiltmovement.
Howtosetupthewiper
1.GotoPTZ>Advanced>Device.
2.Tosetthedurationofthewipersequenceinseconds,enteravaluefortheWiperdwelltime.
Note
Thesetvalueappliesonlytothewipersequenceandhasnoeffectonhowlongthewiperoperatesaspartofthewasher
sequenceifoptionalwasherisused.
3.ClickSave.
Howtosetupthewasher
Note
Thewasherisoptional.
1.GotoLiveView.
2.ClickSetemulatedjoystickmode,seePTZControlsonpage14.
3.Usethejoysticktopositionthewashernozzleinthecenteroftheliveviewimage.
4.GotoPTZ>Advanced>Device.
5.SelectNozzlePosition.
6.GotoSystemOptions>Ports&Devices>I/OPorts.
7.SelectOutputfromtheI/OPortTypedrop-downlistfortheI/Oportusedwiththewasher.
8.GotoPTZ>Advanced>Device.
9.ToselecttheI/Oportthewasherisconnectedto,enteravaluefortheWasherpumppin.
10.Tosetthedurationofthethewashersequenceinseconds,enteravaluefortheWasherpumptime.Thewiperstartswhen
thereis5secondsleftofthistime.
11.Tosetthedurationofthewipersequenceinseconds,enteravaluefortheWasherwipertime.
12.ClickSave.
Thebelowtableprovidessomeexamplesofdifferentwasher-wipersequenceset-ups.
Timeelapsed(seconds)
Washerpumptime:10s
Washerwipertime:10s
Washerpumptime:20s
Washerwipertime:12s
0
WasherstartsWasherstarts
5
Wiperstarts
—
10
Washerstops
—
15
WiperstopsWiperstarts
20
—
Washerstops
22
—
Wiperstops
37
