AXISQ87BispectralPTZNetworkCameraSeries
13.Replacethepositioningunitonthebaseunitmakingsurethatthearrowsonthetwo
unitsarealigned.
14.Turnthepositioningunitclockwisebacktoitsoriginalpositionandtightenthefour
baseunitscrews(torque3.0Nm).
NO NO
NO
TICE TICE
TICE
Makesurethatthecablesdonotgetpinchedwhenmountingthetwounits.
