AXISQ8752-EBispectralPTZNetworkCamera
Specifications
Powerconnector
4-pinterminalblockforpowerinput.
24VAC/DCpowerconnector
NO NO
NO
TICE TICE
TICE
Thissectionisvalidforproductspoweredby24VACand24VDConly.
Thistableisonlyvalidforthe24VACandthe24VDCpowerconnectors.
Position
24VAC24VDC
1
ProtectiveearthProtectiveearth
2
24VACPhase
+24V
3
24VACNeutral
0V
4
NotconnectedNotconnected
Illuminatorconnectors
Position
Cablecolor(positioningunit)Cablecolor(illuminators)
Description
1
RedRed+24VIL
2
Black
Orange
IL1+VE
3
Gray
PurpleIL1-VE
IL1
4
BlueBlack
GND
5
YellowRed+24VIL
6
OrangeOrange
IL2+VE
7
WhitePurpleIL2-VE
IL2
8
Green
Black
GND
