AXISQ9216-SLVNetworkCamera
Thedeviceinterface
-:Dragtheslidertosetthethicknessforthetopborder.
-:Dragtheslidertosetthethicknessfortherightborder.
-
:Dragtheslidertosetthethicknessforthebottomborder.
-
:Dragtheslidertosetthethicknessfortheleftborder.
-Bordercolor:Selectabordercolor.
•Mainview
-Source:Selectthecamerathatwillstreamonthefulldisplay.
-Rotateimage180°:Clicktorotatetheimage.
-Mirrorimage:Clicktoiptheimage.
Powersettings
Powersettings
Delayedshutdown:Turnonifyouwanttosetadelaytimebeforethepoweristurnedoff.
Delaytime:Setadelaytimebetween1and60minutes.
Accessories
I/Oports
Usedigitalinputtoconnectexternaldevicesthatcantogglebetweenanopenandclosedcircuit,forexamplePIRsensors,dooror
windowcontacts,andglassbreakdetectors.
UsedigitaloutputtoconnectexternaldevicessuchasrelaysandLEDs.YoucanactivateconnecteddevicesthroughtheVAPIX®
ApplicationProgrammingInterfaceorinthedeviceinterface.
Port
Name:Editthetexttorenametheport.
Direction:
indicatesthattheportisaninputport.indicatesthatit’sanoutputport.Iftheportiscongurable,
youcanclicktheiconstochangebetweeninputandoutput.
Normalposition:Click
ifthenormalpositionshouldbeopencircuit,andifitshouldbeclosedcircuit.
Activeposition:Showsthecurrentstateoftheport.Theinputoroutputisactivatedwhentheactivepositionisdifferentfrom
thenormalposition.Aninputonthedevicehasanopencircuitwhenit’sdisconnectedorwhenthereisavoltageabove1VDC.
Note
Duringrestarttheoutputcircuitisopen.Whentherestartiscomplete,thecircuitgoesbacktothenormalposition.Ifyou
changeanysettingsonthispage,theoutputcircuitsgobacktotheirnormalpositionsregardlessofanyactivetriggers.
Supervised:TurnontomakeitpossibletodetectandtriggeractionsifsomeonetamperswiththeconnectiontodigitalI/Odevices.
Inadditiontodetectingifaninputisopenorclosed,youcanalsodetectifsomeonehastamperedwithit(thatis,cutorshorted).
Tosupervisetheconnectionrequiresadditionalhardware(end-of-lineresistors)intheexternalI/Oloop.
Logs
Reportsandlogs
