Axis S2008 User Manual

AXISCameraStationS20ApplianceSeries
Managethebuilt-inswitch
PoEtab
InthePoEtab,youndformationaboutthesetupandstatusofpoweroverEthernet(PoE)foreachportandforthePoEenabled
devicesasawhole.Thisdataisusefulforsetting,enabling,disabling,andmanagingtheswitch’spowerbudget.
PaneFunctionDescription
PortstatusPort#Theapplianceportnumbertowhichtheselecteddeviceisconnected.
LinkstateUpindicatesthatadeviceisconnectedtothisport.
Downindicatesthatnodeviceisconnected.
PoEmodeTypeofdevicetheswitchhasdetected.Thisisnotcongurable,the
valuesareassignedbytheswitchbasedonitsinteractionandpower
drawoftheconnecteddevice.
PoEmodevaluesareeitherATorAF.ThesevaluesrefertotheIEEE
802.3atorIEEE802.3afstandards.
PoEclassTypeofdevicetheswitchhasdetected.Thisisnotcongurable,the
valuesareassignedbytheswitchbasedonitsinteractionandpower
drawoftheconnecteddevice.
PoEClassvaluesrangefrom0to4andcorrespondtothefollowing
propertiesasdenedintheIEEEstandard:
Cl-
ass
Usage
Classica-
tionCurrent
(mA)
Power
Range
(watts)
Class
Description
0
Default
0-40.44-12.94
Classica-
tionunim-
plemented
1
Optional
9-120.44-3.84
Verylow
power
2
Optional
17-203.84-6.49
Lowpower
3
Optional
26-306.49-12.95
Midpower
4
Validfor802.3at
(Type2)devices;
notallowedfor
802.3afdevices
36-4412.95-
25.50
Highpower
PowerdrawTheaveragenumberofwattstheconnecteddeviceisconsuming.
PowerlimitDisplaysadefaultlimitbasedonthePoEmodeandclass.
PoEenabledAllowsyoutoviewandchangethePoEenabledordisabledstatustoturn
thePoEtothedeviceonorofffordevices.
DevicesrequiringPoEwillbeturnedoffwhendisabledandthelinkstate
willchangetoDown.
PoEadministrationWattsscale
Theamountofpower(inwatts)drawnbyalldevicescurrentlyconnected
totheswitch.
TotalPoEusage
Thetotalpowerconsumed(inwattsandpercentages)byallconnected
devices.
Thisinformationishelpfulwheninstallingdevicesandverifyingyour
powerbudget.
