Axis S2008 - Back Panel and LED Indicators

AXISCameraStationS20ApplianceSeries
Productoverview
BackPanelAXISCameraStationS20Series
1
Powerconnector
2
PoEenablednetworkconnectors,port1–8,1–16or1–24
3
U1switchuplink,RJ45connector
4
SFP1switchuplink,SFPconnector
5
U2servernetwork,RJ45connector
6
USB3.0connectorx2
7
SFP2servernetwork,SFPconnector
8
eSATAconnector
9
HDMIconnector(audiooutputsupported)
10
VGAconnector
LEDIndicators
LEDindicator
Color
Indication
SystemPowerLEDSteadygreenOn
DiskactivityFlashingyellow
Read/write
PoEports
Steadyred
Portconnected
17
