Axis T8341 - How to Program the Z-Wave Device

AXIST8341PIRMotionSensor
HowtoprogramtheZ-Wavedevice
HowtoprogramtheZ-Wavedevice
Note
ProgrammingZ-WavedevicesusingaZ-Wavecontrollerisrecommendedforexperiencedusersonly.
Z-WaveGroup
ThedevicesupportstwodifferentZ-WaveAssociationGroups:
•Group1:Associationwith1Controllernode.
•Group2:Associationwith4nodes(i.e.end-devicessuchassmartplugsandotherlightingcontrollers).Thisallowsthe
devicetosendcommandsdirectlytootherdeviceswithouttheparticipationofthecontroller.Thishastheeffectthat
whenthedevicetriggers,allotherassociateddeviceswillalsobeoperated.
Note
AssociationgroupsupportcanvaryamongZ-WaveControllers.TheAXISM5065supportsZ-WaveAssociationGroup1.
Group1commands:
•WhenthedeviceispoweredupandisalreadyapartofaZ-Wavenetwork,itwillsendaNoticationReporttothenode
inGroup1.
•Whenthedetectorsensesmovement,theunitwillsendaNoticationReporttothenodesinGroup1.Whenmovement
stops,aNoticationReportwillbesentagaintoGroup1.
•Whenthedetector’sstatuschanges,thedevicewillsimultaneouslycheckitsbatterystatus.Ifthebatteryleveldropstoan
unacceptablelevel,thedevicewillsendabatteryreporttothenodesinGroup1.
•Whenyouperformafactoryreset,theunitwillsendDeviceResetLocallyNoticationtothenodeinGroup1.
Group2commands:
•Whenthedetectoristriggered,theunitwillsendBASIC_SETcommand,containingavalue,tothenodesinGroup2.
Z-WavePlus® ®
®
info
RoletypeNodetypeInstallerIconUserIcon
SlaveSleepingreport
Z-WavePlusnode
SensorNoticationDeviceType
(HomeSecurity)
SensorNoticationDeviceType
(HomeSecurity)
Version
Protocollibrary
3(Slave_Enhance_232_Library)
Protocolversion
4.3D(6.71.01)
Manufacturer
ManufacturerID
ProductTypeProductID
0x03640x00020x0001
AGI(AssociationGroupInformation)table
7
