Axminster AC1950B - Page 15

Illustration and Parts Description
15
Blade guide adjusting knob (E)
Blade guide clamp F)
Tilt quadrant (G), Tilt scale (H)
Tilt scale pointer and adjusting screw (I), Lift and shift handle (J)
Push stick
Blade tensioning scale
Motor assembly
Dust extraction outlet
Table levelling stop bolt
F
E
G
H
I
J
AC1950B Bandsaw
