Axminster AC1950B - Page 16

Illustration and Parts Description
16
Upper blade guide assembly for AC2305B and AC2606B Bandsaw
Rear thrust bearing and clamping grub screw (A) Fore and aft clamping grub screw (B)
Upper blade guide assembly for AC1950B Bandsaw
Rear thrust bearing and clamping grub screw (C) Fore and aft clamping grub screw (D)
Drive assembly for AC2305B and AC2606B Bandsaw
Drive pulley (E) and tensioning Idler wheel (F)
Drive assembly for AC1950B Bandsaw
Two speed drive pulley (G)
