Axminster MB9020 - Parts Illustration and Description 11

WHITE
AXMINSTER
W
12
Parts Illustration and Description...
12. Timber Extention Support 19. Thicknessing Scale/Pointer
13. Fence Lift & Shift Handle 20. Knife Clamping Bolts
14. Infeed Table Depth Scale/Pointer 21. Cutterblock Knife
15. Dust Extraction Port Assembly (Page 02) 22. Chipbreaker/Wedge
16. Dust Extraction Locking Knobs 23. Anti-kick Back Fingers
17. Extraction Port Lug 24. Dry Feed-in Rollers
18. Thicknessing Table
13
18
19
8a
8b
