Axon Body 2 User Manual

Chapter 4: Notification Reference Tables 15
Axon Body 2 Camera User Manual
Battery LED in an Axon Dock
When an Axon Body 2 camera is in an Axon Dock, the Battery LED displays the battery’s charge
status.
Battery Charge Battery LED
Fully charged (capacity greater than 98 percent)
Green
Charging in progress (capacity is 20–98 percent) Yellow
Charging in progress(capacity less than 20 percent) Red
Status LED
When you plug your camera into the Axon Dock, the camera status LED displays the device status.
Device Status Status LED
Initial connection (momentary) Solid red (for 20 seconds or fewer)
In queue awaiting upload Solid yellow
Device ready (all videos uploaded successfully) Solid green
Device not assigned, agency mismatch, camera
set in the oine mode, or device error
Blinking red
Uploading data Blinking yellow
Firmware update, internal battery charging,
extremely low battery, or memory full
Blinking red and yellow – DO NOT remove the
camera from the Axon Dock
Transfer error, device re-trying to transfer Blinking green and yellow
Possible network error. Verify Axon Dock is
registered and refer to the Troubleshooting
chapter of the User Manual or go to help.axon.
com.
Blinking red, yellow, and then green (cycling all
colors)
Axon Dock has no communication with the
camera. Verify the Axon Dock core and bays
are seated properly. Contact Axon Technical
Support if not resolved.
LED o

Axon Body 2 Specifications

General

Frame Rate	30 fps
Storage	64 GB
Pre-Event Buffer	Up to 2 minutes
Water Resistance	IP67
Operating Temperature	-4°F to 122°F (-20°C to 50°C)
Field of View	143 degrees
Battery Life	12 hours
Video Resolution	1080p
Weight	148 g (5.2 oz)
