Axon Cerebrum CGP-4848 User Manual

5
1
Introduction to Cerebrum
An Introduction to
Cerebrum
In modern broadcasting, the multi-platform delivery and multi-
purpose repackaging of materials demand that you master a
diversity of workflows. AXON’s Cerebrum software application
makes the implementation of multiple video and audio signal paths
easier, more efficient and cost-effective than ever. Cerebrum
provides comprehensive tools to configure,monitor and maintain
not only the complete range of Axon products, but also a wide
variety of other devices.
The result is that you, and limitless numbers of users, can take total
control over multiple and complex routines. Ultimately, you can
make your work flow how you want it to flow.
Please visit the AXON Digital Design Website at www.axon.tv to
obtain the latest information on our new products and updates.
Key Cerebrum
features
Cerebrum is a Windows-based application whose advanced
functionality and broad range of features make life easier. The
brains behind your many and varied workflows, Cerebrum allows
users to remotely:
▪ Configure… a complex workflow in a short space of time.
▪ Manage & Report… events using hierarchical system status.
▪ Control… devices via an intuitive, user-friendly graphical
interface.
▪ Maintain… a workflow over its lifetime.
Cerebrum employs Ethernet communication to each device in your
chosen workflow, providing the ability to both configureand
monitor devices at local and remote sites. It uses an SQL database
to record, view and archive historical workflow events as well as
store the user-definable aspects of each device’s configuration. This
database can also be redeployed for the user’s own requirements via
ODBC or similar interface.
The application allows up to 64 user-groups to be defined. For each
group the level of access can be restricted, not only to program
functionality but also to control access of individual settings on
specific devices. Limitless users can be added and assigned to one
of these groups, each with their own unique password. This ensures
that Cerebrum can be used in operations where conditional access is
required, and as an administrative tool.

Axon Cerebrum CGP-4848 Specifications

Power

AC PSU voltage	100–240 V AC
AC PSU current	1.2 A
AC PSU frequency	50/60 Hz
panel input voltage	12 V DC
panel input current	2.0 A

Operating Environment

operating temperature	0º to 40º C
storage temperature	-20º to 70º C

Weight and Dimensions

height	45 mm
width including front panel	484 mm
depth including front panel and DC connector	195 mm
width excluding front panel	450 mm
depth excluding front panel including DC connector	175 mm
weight excluding power adapter	2.5 kg
