Axon Cerebrum CGP-4848 User Manual

17
8
Specifications
Dimensions
Height
45mm (1.73”) (1RU)
Width (including front panel)
484 mm (19”)
Depth (including front panel and DC
connector)
195mm (7.67”)
Width (excluding front panel)
450 mm (17.71”)
Depth (excluding front panel, including
DC connector)
175mm (6.88”)
Weight
Weight (excluding power adapter)
~2.5 kg
Power
AC PSU
Panel input
100–240V AC - 1.2A, Frequency: 50/60 Hz
12V DC - 2.0A
General Purpose Inputs
Input Voltage range
Typical input current
5-12Vdc +/- 10% (4.5V – 13.2V)
5mA (5Vdc input)
General Purpose Outputs
Maximum Voltage
Maximum Current
Max. Switching capacity
Contact resistance
Expected life
220Vdc, 250Vac
2 A
60W
< 70mOhms
> 5 x 10
5
operations
Local Output Voltage (Input connectors pin 19)
Voltage
Maximum Current
5Vdc +/- 10%
400mA
Miscellaneous
Operating temperature
0º to 40º C environmental temperature (32º to 104º F)
Storage temperature
-20º to 70 º environmental temperature (-4º to 158º F)

Axon Cerebrum CGP-4848 Specifications

Power

AC PSU voltage	100–240 V AC
AC PSU current	1.2 A
AC PSU frequency	50/60 Hz
panel input voltage	12 V DC
panel input current	2.0 A

Operating Environment

operating temperature	0º to 40º C
storage temperature	-20º to 70º C

Weight and Dimensions

height	45 mm
width including front panel	484 mm
depth including front panel and DC connector	195 mm
width excluding front panel	450 mm
depth excluding front panel including DC connector	175 mm
weight excluding power adapter	2.5 kg
