Axon Cerebrum CGP-4848 User Manual

15
7
Reprogramming the CGP-4848
Enter Bootmode
The firmware on the unit can be reprogrammed via an Ethernet
connection by using a web page available when the unit is in its
bootloader mode.
To put the unit into its bootloader mode make sure the unit has been
removed from the system, the quickest and easiest way to do this is
to change the IP address of the device in the system view to another
IP address temporarily. Then select the Engineering →
Configure Cerebrum Hardware option under the View
menu. This will present a dialog as shown below.
Enter the IP address of the device and then press Connect. When
connected press the Enter Bootmode and then Cancel to quit this
dialog.
Upgrading the
panel’s firmware
When the unit is in this mode, it will host a webserver at its IP
address. If you use a web browser and type in the IP address in the
address bar it will display the following page:

Axon Cerebrum CGP-4848 Specifications

Power

AC PSU voltage	100–240 V AC
AC PSU current	1.2 A
AC PSU frequency	50/60 Hz
panel input voltage	12 V DC
panel input current	2.0 A

Operating Environment

operating temperature	0º to 40º C
storage temperature	-20º to 70º C

Weight and Dimensions

height	45 mm
width including front panel	484 mm
depth including front panel and DC connector	195 mm
width excluding front panel	450 mm
depth excluding front panel including DC connector	175 mm
weight excluding power adapter	2.5 kg
