19
MICROSPEED
REV 04/05
Electrical Characteristics
Below is a table showing the electrical characteristics of
our recommended filters. Pay particular attention to leakage,
differential adjustements, and nominal current in
accordance with operational temperature.
Filters
Type Current Leakage Curr. Power loss Weight
(A) (mA) W Lb.
SCHAFFNER FN355 3(40°C) 0.07 (400V 50Hz) 1.5 0.55
SCHAFFNER FN2070 3(40°C) 0.4 (250V 50/60Hz) 0.55
TIMONTA FMW4 4(40°C) <0.5 (400V 50/60Hz) 1 0.6
TIMONTA FSS2 3(40°C) <0.5 (250V 50/60Hz) 0.6
TIMONTA FSS2 6(40°C) <3 (250V 50/60Hz) 0.6
Mechanical dimension
