Axor Microspeed 12 - Microspeed Drive Inputs and Outputs

5
MICROSPEED
REV 04/05
The Following are descriptions of the output drive connector.
1 Drive OK NC (open collector max current 100mA)
2 Demand current
3 Common zero signal
4 Auxiliary output voltage +10 volts 4 mA ma x
5 Auxiliary output voltage -10 volts 4 mA ma x
6 Enable(+10/30 volt drive enabled )
7 Input speed reference +(Non inverting input)
8 Input speed reference -(inverting input)
9 Tacho input +
10 Tacho input -
+AT Power supply input positive pow. supply
- AT Power supply input negative pow. supply
+M Positive motor terminal
- M Negative motor terminal
1.3 Inputs and Outputs
Power terminals
Signal terminals
