AXTON A480DSP - Technical Specifications and Features; Technical Specifications; Main Features; Functionality and Adjustability

– 4 –
– 5 –
TECHNICAL SPECIFICATIONS
Music Power Output:
RMS Power Output:
Frequency response:
Audio sampling frequency:
Distortion:
Supply voltage range:
150 W x 4 (110 W x 4*)
76 W x 4 (56 W x 4*)
20 Hz ~ 20 KHz
48 KHz
1 KHz < 0.001%
9 V – 15 V
Signal to noise ratio: > 120 dB
Dynamic range: > 100 dB
Standby current: < 0.4 mA
Maximum operating current: 20 A
Dimensions (L x W x H): 182 x 132 x 52 mm
*without additional power supply
MAIN FEATURES
n 4-channel Smart Digital Amplier with Android App controlled audio DSP functions
n Plug’N’Play quick installation system via vehicle brand and model specic ISO wire
harness
FUNCTIONALITY & ADJUSTABILITY
n Bluetooth connection and control of DSP settings via android Smartphone App
n Time Alignment in cm for front and rear channel output (0 – 400 cm)
n Freely configurable 7-band graphic Equalizer
n 5 different pre-set EQ, Classical, Rock, Theatre, Jazz, Pop, Bass Booster
n 3D surround sound
n Dynamic Bass setting
