AXTON A480DSP - Wiring Diagram

– 6 –
– 7 –
WIRING DIAGRAM
DIMENSIONS
1 11 GND
2 12 +B
3
RR-in
13
FL+out
4
RR+in
14
FL-out
5
RL-in
15
FR+out
6
RL+in
16
FR-out
7
FL-in
17
RL+ o ut
8
FL+in
18
RL-out
9
FR-in
19
RR+out
10 FR+in 20 RR-out
20
SPEAKER
52 mm
152 mm
132 mm
(30A)
If you want to use just the DSP function of the A480DSP with a separate high performance
amplifier, connect the line out of the A480DSP with the RCA input of your amplifier.
FUSE
BATTERY (+)
GROUND (-)
(30A)
POWER LED
DSP EFFECT
ON/OFF
SPEAKERFRONT/REAR
LINE OUT
