Chapter 1. OVERVIEW

zCertification

• UL: File No. MH27717

• CE

*: Gas Appliance Directive

0063BS1427 (with AUR450C seriesand Q241A104)

0063CN6671 (with RX-R4-C series)

RoHS Directive

• FM: File No. 0003059531

*CE marking appears to comply with RoHS

zCombined burner controller

Model Name

RX-R40, RX-R44, RX-R46 Burner Control Module

AUR300C, AUR350C Advanced Ultraviolet Burner Controller

AUR450C Dynamic Self-Checking Burner Controller

zMaintenance/optional parts

Model Name

AUD60A1000 AUD Maintenance Kit *

81446924-001 Flange unit (Standard type)

81446924-101 Flange unit (Condenser type)

81447495-001 Nut packing

81447509-001 Bushing 1×3/4

FSP136A100 Analog flame meter

*1 AUD60A1000 Maintenance Kit

The AUD Maintenance Kit incorporates the tube and shutter units (tube unit:

AUD10, shutter unit: AUD50), including expendables like the expiration date

label*

and the O-ring used for sealing between the flange and cover of the AUD.

*2 Expiration date label Position of the expiration date label

Shutter unit

Thermo label

Label

Tube unit

Tube unit retaining screws (2)

Terminal G (yellow lead wire)

Terminal F (blue lead wire)

Terminal for shutter driver

connection (white lead wire)

Azbil AUD300C1000 User Manual
