B2 Audio RAGE SERIES - Strapped Control Panel Setting; Master Amplifier Setup for Linking; Slave Amplifier Setup for Linking

Strapped control panel setting
11
master amplifier
Bass remote
slave amplifier
output power. Follow the instructions carefully as it can cause harm to your system if done incorrect.
Speaker impedance 2 Ohm ~ 16 Ohm
will reach thermal at a faster rate & will eventually go into protect.
Strapped impedance load under 2 ohm is not warranted!
