4 Design and Construction
4.1 Control Elements
HVA control and connection components are located on two panels.
Panel orientation
Orientation Description
Front
• Test controls and emergency shutdown
• HV status information
Right side
• Cable and power source connections
• External connections (for remote controls)
• RS232 port/USB flash adapter
Right side panel
Left side panel
Front panel
