B2 HVA90 - Page 51

6
Reporting Procedure
© b2 electronic GmbH
DHV0078 b2 EN
51
Step
Procedure
(Reporting)
Example
R7:
Region
(Extended only)
Specify region name
R8:
Station
(Extended only)
Specify station name
R9:
Line length
(Extended only)
Specify line length
• Units correspond to “Distance Unit” set in
“Instrument Settings”
(see 4.3 – Instrument Setup)
R10:
DUT size
(Extended only)
Specify DUT size
Typical entries include:
• Conductor size for cable test
• Horsepower or kW for motor test
R11:
Manufacturer
(Extended only)
Specify manufacturer name
R12:
Work order
(Extended only)
Specify work order name
R13:
Operator
(Extended only)
Specify operator name
Start New / Report Details
Region Name?
region CHEROKEE
MAIN PREV NEXT
DUT: 1.0kV Cable XLPE
Start New / Report Details
Station Name?
station BETA1
MAIN PREV NEXT
DUT: 1.0kV Cable XLPE
Start New / Report Details
Line Length?
linelen 200 meter
MAIN PREV NEXT
DUT: 1.0kV Cable XLPE
Start New / Report Details
Size of DUT?
size 4/0
MAIN PREV NEXT
DUT: 1.0kV Cable XLPE
Start New / Report Details
Manufacturer Name?
manufacturer ABC
MAIN PREV NEXT
DUT: 1.0kV Cable XLPE
Start New / Report Details
Work Order?
W.Order: WOO9A
MAIN PREV NEXT
DUT: 1.0kV Cable XLPE
Start New / Report Details
Operator Name?
operator J.SMITH
MAIN PREV NEXT
DUT: 1.0kV Cable XLPE
