B2 HVA90 - Page 55

7
Disconnection Procedure
© b2 electronic GmbH
DHV0078 b2 EN
55
Step
Procedure
(normal disconnection)
D6 Disconnect the test lead
• Disconnect the test lead from the DUT
• Unscrew the test lead from the HV output connector
D7
Disconnect power supply cable from power supply plug
D8 Disconnect earth
• Disconnect the earthing cable from the HVA earthing connector
• Disconnect the earthing cable from the DUT
Discharge Stick
