NAMES OF MACHINE PARTS AND THEIR FUNCTIONS
7
Options Removing the LCD cover
a
While pressing down on the latch at the top
of the LCD cover, pull the cover towards
you.
a Latch
b
Remove the LCD cover.
123
456
789
No. Part Name Part Code
1 Side cutter foot XC3923-001
2 Seam guide BLG-SG
3 1/4” quilting foot with guide XC6800-251
4 Embroidery bobbin thread
(White)
BBT-W
Embroidery bobbin thread
(Black)
BBT-B
5 Table and free motion grip BLG-ET
6 Embroidery card
7 Spool stand BLG-TS
8 Embroidery frame set (extra
large) H 26 cm x W 16 cm
(10 – 1/4 inches (H) x
6 – 1/4 inches (W))
EF81: Frame
EF86: Embroidery sheet
9 2-thread spool stand BLG-STS
Memo
• All specifications are correct at the time of
printing.
Please be aware that some specifications
may change without notice.
Note
• Embroidery cards purchased in foreign
countries may not work with your machine.
• Use Baby Lock embroidery cards with your
machine. Please see your retailer for
availability of additional embroidery cards.
• Visit your Baby Lock retailer for a complete
listing of optional accessories available for
your machine, or visit the Baby Lock web
site at www. babylock. com.
To Next Page
