4
G75-DFC
Differential Filtration Controller
INTRODUCTION
General
The Baccara Differential Filtration Controller combines a Controller and a Differential Pressure Sensor (DP).
The Controller has seven wires; four wires for valves, and a molded 3 wire cable with connector for the DP switch.
The G75-DFC operates up to three G75 4
Ω latch two-wires solenoids, and has a display screen that shows the actual
differential pressure (DIF) and the pressure SET point.
The Flushing Cycle (FC) begins when the DIF reading is greater than or equal to the SET value.
Display:
The LCD display shows:
• The actual differential pressure - DIF
• The pressure set point - SET
• The flushing cycles counter - FC
• While in flushing, a Faucet icon appeases on screen
• When the battery needs replacing, a Low Battery icon appears on screen
Technical Data
Controller Set | Supplied with DFC controller, suitable for DC only, and one analog sensor
Mechanical
• Operating temperature: -10ºC to 60ºC
• Outdoor UV protection
• Front panel cover protection
• “H” proof pressure: 14 bar (203 PSI)
• “H” pressure must be ≥ “L” pressure
Electrical
DC units are powered by single 9V alkaline battery.
• Back-up memory
• Low battery warning
• Power saving LCD
Mounting
• Pressure ports 1/8” BSP/NPT (male)
• High pressure port is marked by the letter “H” on the housing
• Connect high pressure before low pressure
• Disconnect low pressure before high pressure
Controller:
• Directly on a 28mm diameter solenoid in horizontal or vertical position with adaptor
• Wall mounting with four screws
• Accessories provided | Sensor: 2” (52 mm diameter)
Software
See the “Programming” chapter of this document
Options
Option to change default factory settings
Standard protection class
IP66 | Dust and watertight
Solenoid
G75-A, GALIT Latch 4Ω, G75-A3P 1Ω
