Note - Go into IR DIGIPOT and
verify that the MW is not set outside
the range of 300 to 500 after
adjusting the IR detector voltage IR
DIGIPOT. A typical MW setting for a
sensor with Yellow tape is 325
without the tape it is approx 425.
To adjust the MW use
the up and down arrow
keys on the keypad.
Adjust the Detector Digipot Voltage
Range 4.20 to 4.28 with up and down
Sensor
No Tape
With
Digipot Reference
b
