Backyard Discovery BEACH FRONT - Page 13

Parts Identification
Hardware
AN - BOLT HEX 5/16x2-3/4 - H100047
(4)
LC - LAG SCREW WH 1/4x1-1/2 - H100145
(11)
CH - SCREW TAPPING 14x1-1/2 - H100109
(17)
BA - BOLT PTH 1/4x3/4 - H100063
(13)
KS - NUT BARREL WH 1/4x5/8 - H100136
(2)
KY - BOLT WH 1/4x1/2 - H100141
(2)
CY - SCREW PWH 8x5/8 - H100128
(17)
BN - SCREW PFH 8x1 - H100085
(13)
BR - SCREW PFH 8x1 1/8 - H100088
(92)
BP - SCREW PFH 8x1 1/2 - H100086
(96)
BS - SCREW PFH 8x1 3/4 - H100089
(60)
CK - SCREW PFH 8x2 - H100111
(13)
BT - SCREW PFH 8x2 1/2 - H100090
(26)
CB - WASHER SAFETY 17x30 - H100103
(7)
CD - WASHER FLAT 8x27 - H100105
(16)
CE - WASHER FLAT 9x18 - H100106
(11)
CG - WASHER LOCK INT 8x15 - H100108
(24)
CJ - NUT LOCK 5/16 - H100110
(9)
KV - WASHER LOCK EXT 6x15 - H100138
(10)
KW - WASHER LOCK EXT 8x15 - H100139
(2)
AZ - BOLT PTH 1/4x1 1/4 - H100062
(2)
-
T
-
3
0
T
O
R
X
W
R
E
N
C
H
-
H
1
0
0
1
1
4
(
2
)
-
T
-
3
0
T
O
R
X
B
I
T
-
H
1
0
0
1
4
7
(
2
)
-
T
-
4
0
T
O
R
X
B
I
T
-
A
1
0
0
0
4
2
(
2
)
-
T
-
4
0
T
O
R
X
W
R
E
N
C
H
-
A
1
0
0
0
4
1
(
2
)
AC - WASHER LOCK EXT 8x19 - H100030
(105)
AD - WASHER LOCK EXT 12x19 - H100031
(22)
BX - WASHER SPLIT 5/16 - H100095
(4)
AJ - BOLT HEX 5/16x1 1/4 - H100042
(4)
BQ - SCREW PFH 8x1 1/4 - H100087
(39)
BM - SCREW PFH 6x3/4 - H100084
(4)
