Backyard Discovery BEACH FRONT - SWING BEAM ASSEMBLY

SWING BEAM ASSEMBLY
STEP 1
BOLT HEX
5/16x2-3/4
(2)
BOLT WH
5
/16x1 3/4
(3)
NUT BARREL
WH 5/16x7/8
(3)
WASHER
FLAT 8x27
(4)
NUT LOCK
5/16
(2)
SB74 - SWING BEAM EXTENDED - W4L06961
2
"x5 1/4"x89 1/2" (50x134x2274)
(1)
- SWING BEAM EXT. BRACKET BLUE - LEFT - A4M00511
(1)
- SWING BEAM EXT BRACKET BLUE - RIGHT - A4M00512
(1)
GQ - L BRACKET 66x66x127 BLUE - A100153
(2)
BOLT HEX 5/16x2-3/4
(2 PLCS)
WASHER FLAT 8x27
(4 PLCS)
NUT LOCK 5/16
(2 PLCS)
BOLT WH 5/16x1 3/4
(3 PLCS)
NUT BARREL WH 5/16x7/8
(3 PLCS)
SWING BEAM EXT BRACKET BLUE - RIGHT
SWING BEAM EXT. BRACKET BLUE - LEFT
L BRACKET 66x66x127 BLUE
(2 PLCS)
SB74
