Anchoring Instructions
FINAL STEP
DOUBLE CHECK EVERY BOLT, SCREW AND NUT FOR TIGHTNESS. MAKE SURE EVERY BOARD IS
SECURE AND MAKE SURE THE PLAY SET IS LEVEL.
ENJOY YOUR NEW PLAY SET!
NOTE:
FAILURE TO USE GROUND STAKES CAN
VOID WARRANTY & CAUSE INJURY!
STEP 38
TAP IN GROUND STAKES AT AN APPROXIMATE 45° ANGLE AT THE LOCATIONS SHOWN.
USING GROUND STAKES AS A GUIDE, DRILL 7/16" DIA HOLES.
«
S
P
A
N
I
S
H
- GROUND STAKE REBAR - A4M00527
(8)
BOLT WH 5/16x1 1/4
(2 PLCS)
WASHER LOCK EXT 12x19
(2 PLCS)
NUT BARREL WH 5/16x5/8
(2 PLCS)
NUT BARREL WH 5/16x5/8
(4 PLCS)
WASHER LOCK EXT 12x19
(4 PLCS)
BOLT WH 5/16x1/2
(4 PLCS)
BOLT WH 5/16x1/2
(2 PLCS)
WASHER LOCK EXT 12x19
(2 PLCS)
NUT BARREL WH 5/16x5/8
(2 PLCS)
BOLT WH
5
/16x1 1/4
(2)
WASHER
L
OCK EXT
12x19
(8)
NUT BARREL
WH 5/16x5/8
(8)
BOLT WH
5
/16x1/2
(6)
GROUND STAKE REBAR
(8 PLCS)
